UHMW-PE face pad/UHMW-PE face pad/UHMWPE pad

UHMW-PE Face pad/UHMW-PE Facial pads/UHMWPE PadGreen UHMWPE Pads for Marine fender/UHMWPE Fender padsBlack dock fender UHMWPE Fender padsUHMWPE or HDPE  FQ 1000 Sliding Fender pads for Marine fenderUHMWPE FENDER PADS Characters : ItemTest MethodUnitUHMWPE 1000-VUHMWPE 1000-DSDensityISO1183-1g/cm30.93-0.950.95-0.96Yield

Featured Products

UHMW-PE Face pad/UHMW-PE Facial pads/UHMWPE Pad
Green UHMWPE Pads for Marine fender/UHMWPE Fender pads
Black dock fender UHMWPE Fender pads
UHMWPE or HDPE  FQ 1000 Sliding Fender pads for Marine fender

UHMWPE FENDER PADS Characters :


Item
Test Method
Unit
UHMWPE 1000-V
UHMWPE 1000-DS
Density
ISO1183-1
g/cm3
0.93-0.95
0.95-0.96
Yield Strength
ASTM D-638
N/mm2
15-22
15-22
Breaking Elongation
ISO527
%
>200%
>100%
Impact Strength
ISO179
Kj/m2
130-170
90-130
Abrasion
ISO15527
Steel=100
80-110
110-130
Shore Hardness
ISO 868
Shore D
63-70
63-75
Friction Coefficient(static state)
ASTM D-1894
Unitless
<0.2
<0.2
Operating Temperature
-
ºC
-80 to +80
-80 to +80


XINXING UHMWPE1000 ultra high molecular weight polyethylene (UHMW-PE) is the first choice material for facing steel fender panels and other heavy duty applications. They also used in corner pad for marine fender cover/ coner marine fender pads for jetty . It combines very low friction with excellent impact strength and a wear resistance much better than steel. Most popular is XINXING UHWMPE1000-DS which is 'double-sintered' and work-hardened for extra durability. The standard colour is black, but if other colours are needed then UHMWPE 1000-V 'virgin' grade also comes in yellow, white, grey, blue, green and red. UHMW-PE1000 materials are compounded to resist ozone and UV radiation. They do not degrade or rot .
UHMW-PE Face pad/UHMW-PE Facial pads/UHMWPE Pad
Green UHMWPE Pads for Marine fender/UHMWPE Fender pads  Characters:
1.very flat on the surface
2.The thickness tolerance is +2 -0,some made according to your requirements.
3.The color is pure and any color can be made by us.
4.We can give you an accurate size of HDPE plate with advanced machine.
5.Different shaped HDPE plate also can be made by us like bending sheet.
6.According to different requirements with different application, special specifications can be customized, like anti-UV, fire-resistant,anti-static and with other characters.


PE 1000 UHMWPE Marine fender pads/board/plate
UHMW-PE Face pad/UHMW-PE Facial pads/UHMWPE Pad
Application case 1
UHMW-PE Face Pad/UHMW-PE Facial Pads/UHMWPE Pad

UHMW-PE Face pad/UHMW-PE Facial pads/UHMWPE Pad
Application case 2
UHMW-PE Face Pad/UHMW-PE Facial Pads/UHMWPE Pad

UHMW-PE Face pad/UHMW-PE Facial pads/UHMWPE Pad
Application case 3
UHMW-PE Face Pad/UHMW-PE Facial Pads/UHMWPE Pad

Green wear-resisting UHMWPE 1000 Fender facing plate/pad/panel  applications:
Bridge buttress protection
* Pontoon pile guide bearings
* Fast-launch lifeboat slipways
* Beltings for smaller workboats
* Fender panel facing pads
*Fender pile rubbing strips
*UE-V fender shields
*Facing strips for jetties and wharves
*Lock entrance and lock wall protection
*Mitres on lock gates
Application  case 1

CNC Machine UHMW-PE Face Pad/UHMW-PE Facial Pads/UHMWPE Pad

PackingUHMW-PE Face Pad/UHMW-PE Facial Pads/UHMWPE Pad


FAQ

Q:Are you a trading company or a manufacturer?

A:We are both, we have our own factory, but also a factory-based trading company.

Q:Can we visit your factory ?

A:Warmly welcome,we located 50 kilometers northeast of Dezhou City. It takes only 1.5 hours from our factory to Beijing and 40 min to high speed railway station.The office has convenient transportation and beautiful environment, which is convenient for receiving guests from all directions.

Q:How can we get the offer?

A:To give you a good price,please offer your company information/trade term;product size/color/quantity

Q: How long is your delivery time?
A: Generally it is 7-15 days if the goods are in stock. or it is 15-25 days if the goods are not in stock, it is according to quantity.

Q: What are your terms of payment term?

A:T/T or L/C at sight. 50% T/T as deposit, balance before shipping.

Q:What are your terms of delivery methods?

A:ocean vessel, train, air plane or truck as arranged under FOB,   CNF/CFR, CIF or DDU terms;

Q:What are your packing way?

 A:pallet with stretch film, carton with stretch film, tray or others as your request.



About Shandong Ningjin Xinxing Chemical Co.,ltd Blue UHMW Polyethylene 1000 Fender pads for Marine fender
UHMW-PE Face Pad/UHMW-PE Facial Pads/UHMWPE Pad\

XINXING Certificate
UHMW-PE Face Pad/UHMW-PE Facial Pads/UHMWPE Pad




SHANDONG NINGJIN XINXING CHEMICAL CO.,LTD Established in 1989, Xinxing Chemical Co.,LTD is the largest manufacture of engineering plastics in China. XINXING 's main products include UHMWPE Sheets ,UHMWPE Rods ,HDPE Sheets ,HDPE rods as well as custom machined parts such as UHMWPE Marine Fender pads ,ground protection mats ,crane outrigger pads ,ice rink barrier,dasher board ,shooting pads,Suction box cover , uhmwpe chain guides ,dock bumpers, ect. In addition to these engineering plastic components and products ...
